SS 316 Rollers Mercerising Machine Heat Source Steam 0.2-0.6 Mpa ISO9001

Roller + clip mercerizing machine & washing range , inverter controlled , SS 316 rollers​

APPLICATION:

The range is used for mercerizing the dry fabric of all cotton and polyester cotton fabric. The wide range can mercerize the wide fabric and sheet fabric.

Process:

fabric feed frame →18 pairs thick alkali chainless mercerizing box→2 bowl high-efficiency squeeze→12.5 pairs Weak alkali stabilize mercerizing box→2 bowl high-efficiency squeeze→(90^.fabric feed frame) →【steam washing box(5/6) →2-bowl padder】X8→steam washing box(5/6)→2 bowl high-efficiency squeezer→2x10 drying cylinder (dia.:800mm)→Fabric outlet

MAIN SPECIFICATIONS:

1. Version:chainless

2. working width:1800-3200m

3. speed: machinery speed 45m/min process speed 40m/min

4. mercerizing zone cloth content: Optional

5. Straight roller: up straight roller coated with nitrile is rubber roller shore-hardness 70℃;down straight roller is stainless steal roller with micro screw in the surface

6. Driving mode:multi-unit alternating synchronouslly mecerizing zone and stability zone use PLC to control automatically,using digit to set up and display and using man-machine interface to operate.

7. Heat source: steam 0.2-0.6Mpa

8. Compressed air pressure: 0.2-0.8Mpa

Electrical Component:

The speed for whole range is controlled by AC frequency conversion. Inverter are Inovance,PLC are Mitsubishi. All operating button and frequency conversion signal are accessed to PLC, controlled and managed uniformly.

Adopting temperature auto-controlling and equipped with PT100 Temperature sensor.

The electrical cabinet has air-conditioner ventilation device.

Electrical components are Schneider brand.

The machine contains the relevant bridge frame and required cabinet and cable.
