PLC Control Textile Finishing Machine For Open Width Knits Textile / Custom Tailor

China VIROCK TEXTILE PRINTING&DYEING MACHINERY CO.,LTD certification
I'm Online Chat Now

PLC Control Textile Finishing Machine For Open Width Knits Textile / Custom Tailor

PLC Control Textile Finishing Machine For Open Width Knits Textile / Custom Tailor
PLC Control Textile Finishing Machine For Open Width Knits Textile / Custom Tailor

Large Image :  PLC Control Textile Finishing Machine For Open Width Knits Textile / Custom Tailor

Product Details:

Place of Origin: CHINA
Brand Name: VIROCK
Certification: ISO9001

Payment & Shipping Terms:

Minimum Order Quantity: 1 SET
Price: NEGOTIABLE
Packaging Details: wooden case
Delivery Time: 90 days
Payment Terms: T/T
Supply Ability: as required
Detailed Product Description
Installation Power.: Depends On The Specifications Main Drive Power: 18.5Kw/22Kw
Fabric Working Width: As Required Machine Color: Optional
Heating Source: Gas/oil/steam/eletricity Rail Length: Custom Tailor
Rail Type: Horizontal Cooling Type: Air-jet Cooling
High Light:

textile finishing equipment

,

cloth finishing machines

Open width knits Textile Finishing Machine , Humanization design , PLC controlled



1. Stenter Application:

Stenter machine is electrical machines used in textile industry for stretching or stentering thin fabrics such as muslin. Stenter electrical machines are called as stenter hook. In stenter open compactor fabrics enter. Here Cotton fabric shrinks widthwise & weft are distorted due to bleeching & dyeing process.





2. Stenter features:



A. Low tension designs for fabric entry.
Chains transporting by individual servo-motor driven system,high precision and easy to maintenance.
Air jet nozzle by air cushion type designs, optimal air dynamic designs,to highlight the fabric quality and handles.
B. Exhaust blower combined with Inverter control,ensure the energy been utilized economically.

C. By virtue of advanced PLC + HMI touch screen interface designs, simple and easy to operate.

D.Transporting system by servo-motor driven.

E. Machine will be finished with red oxide putty & primmer paint and finally with 3 coats of industrial paint. Optionally finished with powder coating process.





3. Technical specifications:



Roller width: 1400-3600mm Working width:

1200-3400mm



Heat source:

nature gas etc



Width adjustment range:

700-3400mm



Chambers No.



optional Temperature of chamber:

100-220℃



Fabric held by:

clip/pin/combined



Air pressure: above 0.5mpa
Overfeed range:

-10% to 80%



Installed power:

Approx 120Kw
