Plaiting / Batching Exit Hot Air Stenter Machine Max Chamber Temperature 230 Degree

Advanced woven Hot air stenter Machine , Humanized design , Inverter controlled

1. The folloing activities are carried out in stenter machines:

1) Application of finishing chemicals,

2) Drying and stretching fabrics,

3) Textile curing,

4) Fabric heat setting,

5) Pigment dyeing

2. Details of the stenter machine:

 Inlet J-scray:

This part is used to store the fabric during the batch change. The inlet unit contains various parts like tension device, draw roll, pressure roll and break roll. The important functions of the above rollers are feed the fabric smoothly throughout the machine.

Padding mangle:

It contains chemical trough, guide rollers and squeezing mangle. Fabric is dipped into the finish chemical then sent to squeezing mangle. During this time finish chemicals are applied on the fabric and squeezes out extra chemicals from the fabric.

Mahlo device (weft straightener):

It has two bow and three skew rollers which correct the skewness and bowingand make the weft yarns straight.

Overfeed system:

To give overfeed or under feed of the fabric to respecitive chain track.

Inlet chain track:

To aid proper pinning or clipping of the fabric.

3.Technical data:
